DC 12V/24V LED Driver Power Supply Transformer+extension cable+Junction box 15W
💡【12V/24V in One】ALUSSO LED driver input voltage is 220-240V~50/60Hz, output voltage is ①12VDC/1.25A max; ②24VDC/650mA max. suitable for all 12V and 24V devices, 1 Transformer, 2 Uses, can better save your cost.
💡【Lightweight Body】ALUSSO LED driver has 65g ultra-light weight, height 23mm/0.9inch, length 99mm/3.9inch, width 40mm/1.6inch, compact and lightweight.
💡【High Quality】ALUSSO led driver adopts upgraded design scheme, smaller resistance can drive more electrical devices, reduce line loss and heat, reduce power supply cost. At the same time upgraded short-circuit protection, over-current protection, overload protection, over-temperature protection, higher safety factor, more secure use.
💡【Package Includes】A set includes 2 led drives, 2 junction boxs and 3 1.5m extension cables. Perfectly compatible with our ALUSSO 6-pack 12V tube lights, and can also be adapted to 0-12W devices as needed (power consumption has been calculated) without the need for additional accessories.
Specification
| Power | 15W |
|
Power Factor |
>0.8 |
| Input | 220-240V~50/60Hz |
|
Output |
Mode1:12VDC/1.25A max Mode1:24VDC/650mA max |
|
LED Drive Weight |
65g |
|
LED Drive Size |
W40mm*L99mm*H23mm (2pcs/pack) |
|
Junction Box Size |
W133mm*L38mm (2pcs/pack) |
|
Extension Cable Size |
1500mm 2-Pin (3pcs/pack) |
|
Input Wire Diameter |
0.75-2.5 mm² Querschnitt |
|
Output Wire Diameter |
0.5-2.5 mm² Querschnitt |
| Warranty | ✅ 5 Years |
|
Ambient Temperature(TA) |
40°C |
|
Case Temperature(TC) |
85°C |
